wethepeople "Patron" 2016 BMX Frame (02/2016)

The wethepeople "Patron" 2016 BMX Frame is manufactured for top modern and technical Pro level street riding. Of course this wethepeople "Patron" 2016 BMX Frame is made from best quality, partially heat treated 100% 4130 CrMo and a steep 75.5° degrees head tube paired with a short to mid length 13.1" - 13.25" inch rear end and a 11.75" inch low bottom bracket offers you here a top modern and stable build BMX frame with a balanced overall length and geometry. Furthermore this BMX frame includes high quality made 7mm thick investment cast dropouts, a integrated seat clamp and removable brake hardware and D-shape chainstays for dent resistance.

Facts: wethepeople "Patron" 2016 BMX Frame

• Material: Japanese seamless 4130 crmo tubing, butted tubes, TT and DT with gusset
• Geometry:
  Top Tube (TT): 20.75" or 21.15"
  Chain Stay (CS): 13.1" (slammed) - 13.3" (with 25 - 9 gearing)
  Head Tube Angle (HA): 75.5°
  Seat Tube Angle (SA): 70.5°
  BB Height: 11.75"
  Standover Height: 8.75" (20.75" TT), 9" (21.15" TT)
• Bottom Bracket: Mid BB, 74mm wide, CNC machined, heat treated
• Dropouts: CNC machined, heat treated, 7mm thick, 14mm
• Extras: Removable brakehardware, integrated seatclamp, rearend designed for 2.4" tires, D-shape chainstays for dent resistance
