BMX Race Front Hubs
Build the foundation of a fast wheelset with a smooth-rolling BMX Race Front Hub. Whether you need a standard 10mm bolt-in hub or a stiff 20mm thru-axle model for modern carbon Forks – we have the right hub for your setup. Check the axle compatibility guide below to match your fork dropouts.
BMX Race Front Hubs FAQBMX Race Front Hubs Range
BMX Race Front Hubs FAQ
What is a BMX Race Front Hub and why does it matter?
The Front Hub is the center of your front wheel. While it doesn't transmit drive power, it is crucial for steering precision and low rolling resistance. In modern racing, the stiffness of the connection between the hub and the fork (10mm vs 20mm) plays a huge role in cornering stability.
How is a Race Front Hub constructed?
- Hub Shell
- Usually CNC-machined aluminum. Minimalist design to save weight.
- Bearings
- Sealed cartridge bearings are standard. High-end hubs use ceramic bearings for even less friction.
- Axle System
- The interface to the fork. This is the most important spec to check.
Which Axle Standard do I need? (10mm vs. 20mm)
You must match the hub to your fork's dropouts. There are two main standards:
| Axle Type | Description | Typical Use |
|---|---|---|
| 10mm (3/8") Bolt-In | Female bolts screw into the axle. The classic standard. | Junior, Expert, and many CrMo Pro forks. |
| 20mm Thru-Axle | A thick hollow axle goes through the hub and fork. Extremely stiff. | Modern Carbon Forks (Box, IKON, Meybo). Pro Standard. |
Note: Some hubs offer adapters to convert from 20mm to 10mm, but usually, you buy the specific hub.
What about Spoke Holes?
The number of holes in the hub must match your Rim:
- 28 Holes: Standard for Mini, Junior, and Expert wheels (weight saving).
- 36 Holes: Standard for Pro and Cruiser sizes (stability).
What do the specifications mean?
| Specification | Explanation | Examples/Available |
|---|---|---|
| Axle Size | Diameter of the mounting hardware. | 10mm (Female), 20mm (Thru) |
| Hole Count | Number of spoke holes. | 28H, 36H |
| Bearing Type | Quality of the bearings. | Sealed (Standard), Ceramic (High End) |
