Fiend BMX "Lewis Mills" BMX Frame - black - 21.5"
-
Weight : 2.4kg / 5.29lbs
Weight
The heaviness of a BMX part, measured by weighing. It's worth noting that weight specifications for BMX parts can vary and may not always be precise. Several factors contribute to this:Manufacturer's weight specifications may be inaccurate or incomplete.The weight of two identical parts can also differ.We cannot weigh every individual part.For example, if there are handlebars in different heights, the manufacturer usually provides just one weight specification for all heights. When weighing two identical tires, you might get two different results.Source: BMX Glossary
- Packaging Unit: 1 Piece
- Product ID (PID): 22002
- Product safety
Found an error? Report it. 5 EUR voucher if confirmed.
This
Fiend BMX "Lewis Mills" BMX Frame
is Lewis Mills signature frame and was in accordance to his wishes and his riding style for top modern and technical Pro level street riding designed and manufactured. Of course this
Fiend BMX "Lewis Mills" BMX Frame
is made from best quality, partially heat treated 100% 4130 CrMo and a steep 75.5° degrees head tube paired with a medium length 13.125" rear end and a 9.5" Standover make this high quality Street super solid.
Note: This frame has holes to put brakemounts but there are not included.
Note: This frame has holes to put brakemounts but there are not included.
Facts: Fiend BMX "Lewis Mills" BMX Frame
- Wheel Size: 20"
- Material: 100% 4130 CrMo, top tube and down tube gussets, butted tubes, tapered chainstays, integrated headset
- Geometry:
- Top Tube Length (TT): 20.5", 20.75", 21.0", 21.25" or 21.5"
- Chainstay Length (CS): 13.1" (33.27cm) - 13.5" (34.29cm)
- Head Tube Angle (HA): 75.5°
- Seat Tube Angle (SA): 71°
- Bottom Bracket Height: 11.625" (29.53cm)
- Standover Height (SO): 9.5" (24.13cm) - Seat Clamp: integrated
- Seat Post Diameter: 25.4mm
- Bottom Bracket: Mid BB
- Dropouts: Investment cast, 8mm thick, 14mm slots
- Chain Tensioners: integrated
- Brake Type: U-Brake
- Brakemounts: with (screwable, M8)
- Brakemounts included with delivery: No
- Gyro compatible: Yes
- Features: Lewis Mills Signature frame, wide rear end for fat 2.4" tires
- Model Year: 2026
