Federal Bikes "Jarvis ICS2" 2022 BMX Frame
This product is currently sold out. The date of new availability is unknown.
Current successor: Federal Bikes "Jarvis V2" BMX Frame Show similar products
Current successor: Federal Bikes "Jarvis V2" BMX Frame Show similar products
-
Weight : 2.51kg / 5.53lbs
Weight
The heaviness of a BMX part, measured by weighing. It's worth noting that weight specifications for BMX parts can vary and may not always be precise. Several factors contribute to this:Manufacturer's weight specifications may be inaccurate or incomplete.The weight of two identical parts can also differ.We cannot weigh every individual part.For example, if there are handlebars in different heights, the manufacturer usually provides just one weight specification for all heights. When weighing two identical tires, you might get two different results.Source: BMX Glossary
- Packaging Unit: 1 Piece
- Product ID (PID): 23646
- Product safety
Found an error? Report it. 5 EUR voucher if confirmed.
The
Federal Bikes "Jarvis ICS2" 2022 BMX Frame
is Joe Jarvis' signature frame and was in accordance to his riding style designed and manufactured for top modern and technical Pro level BMX Street riding. The
Federal Bikes "Jarvis ICS2" 2022 BMX Frame
comes with new ICS2 wishbone and smaller, more refined IC dropouts, a slightly taller head tube and with graphics designed by Rich Forne and Joe Jarvis.
Caution: The delivery of the frame is without removable brake bosses, gyro tabs and brake cable holder. The Federal Bikes Brake Mount Kit is available separately in our online shop.
Caution: The delivery of the frame is without removable brake bosses, gyro tabs and brake cable holder. The Federal Bikes Brake Mount Kit is available separately in our online shop.
Facts: Federal Bikes "Jarvis ICS2" 2022 BMX Frame
- Wheel Size: 20"
- Material: 100% 4130 CrMo, top tube and down tube gussets, butted tubes, tapered chainstays, integrated headset
- Geometry:
- Top Tube Length (TT): 20.6"
- Chainstay Length (CS): 13.6" (34.54cm) - 14" (35.56cm)
- Head Tube Angle (HA): 75.5°
- Seat Tube Angle (SA): 71°
- Bottom Bracket Height: 11.8" (29.97cm)
- Standover Height (SO): 9" (22.86cm) - Seat Clamp: integrated investment cast
- Seat Post Diameter: 25.4mm
- Bottom Bracket: Mid BB
- Dropouts: 4130 CrMo, 5mm thick, 14mm slots
- Chain Tensioners: integrated
- Brake Type: U-Brake
- Brakemounts: with (screwable, M8)
- Brakemounts included with delivery: No
- Gyro compatible: Yes
- Features: Joe Jarvis Signature frame, wide rear end for fat 2.5" tires, new investment cast (ICS) chain stay wishbone
- Model Year: 2022
