Haro Bikes "Ryan Nyquist" 2017 BMX Frame
This product is currently sold out. The date of new availability is unknown. Show similar products
-
Weight : 2.35kg / 5.18lbs
Weight
The heaviness of a BMX part, measured by weighing. It's worth noting that weight specifications for BMX parts can vary and may not always be precise. Several factors contribute to this:Manufacturer's weight specifications may be inaccurate or incomplete.The weight of two identical parts can also differ.We cannot weigh every individual part.For example, if there are handlebars in different heights, the manufacturer usually provides just one weight specification for all heights. When weighing two identical tires, you might get two different results.Source: BMX Glossary
- Packaging Unit: 1 Piece
- Product ID (PID): 12014
- Product safety
Found an error? Report it. 5 EUR voucher if confirmed.
The
Haro Bikes "Ryan Nyquist" 2017 BMX Frame
is the signature BMX frame of BMX Park and Dirt legend Ryan Nyquist and is a bold mixture of current day frame technology and geometry mixed with some features and flavor from previous Nyquist signature frames.
The
Haro Bikes "Ryan Nyquist" 2017 BMX Frame
is a high quality full 4130 CrMo frame, hydro-formed pierced top tube and comes with a slightly longer rear end. At the
Haro Bikes "Ryan Nyquist" 2017 BMX Frame
you can find invest cast dropouts, integrated seat clamp, CNC machined head tube, seat tube and bottom bracket.
Facts: Haro Bikes "Ryan Nyquist" 2017 BMX Frame
- Wheel Size: 20"
- Material: 100% 4130 CrMo, top tube and down tube gussets, butted tubes, tapered chainstays, integrated headset, hydro-formed pierced top tube, externally CNC machined seat tube,
- tapered seat/chain stays
- Geometry:
- Top Tube (TT): 21.0"
- Chain Stay (CS): 13.75"
- Head Tube Angle (HA): 75°
- Seat Tube Angle (SA): 71°
- BB Height: 11.5"
- Standover Height (SO): 9.25" - Seat Clamp: integrated
- Seat Post Diameter: 25.4mm
- Bottom Bracket: Mid BB
- Dropouts: Investment cast, 6.5mm thick, 14mm slots
- Chain Tensioners: integrated
- Brakemounts: removable, M8, included with delivery
- Extras: Ryan Nyquist Signature frame, wide rear end for fat 2.4" tires
- Model Year: 2017
