Volume Bikes "Voyager XL" BMX Rahmen - Metal Flake Flat Black (Trevor Antillon)
- Weight (in kg): 2.4
- Weight (in lbs): 5.29
- Packaging Unit: 1 Piece
- Product ID (PID): 22696
The Volume Bikes "Voyager XL" BMX Rahmen - Metal Flake Flat Black (Trevor Antillon) features the same tech feel of the "Voyager V2", but with a little extra length. It has a steeper 75.25º heat tube, Longer 13” slammed chainstay (13.25” center to center), a higher 9.25” seat tube height, and a 20.5” size for shorter riders. This frame also features double butted 4130 heat treated chromoly tubing, hour glass head tube, and small/ clean 6mm thick laser cut and welded dropouts with built in chain tensioner. Added top and bottom gussets for strength, removable brake mounts, and S chainstays for bigger tire clearance.
Facts: Volume Bikes "Voyager XL" BMX Rahmen - Metal Flake Flat Black (Trevor Antillon)
- Wheel Size: 20"
- Material: 100% heat treated 4130 CrMo, top tube and down tube gussets, buttet tubes, tappered chainstays, integrated headseat, integrated seatclamp, removable brake hardware, Mid BB
- Geometry:
Top Tube Length (TT): 20.75" or 21.0"
Chainstay Length (CS): 13" (33cm) - 13.3" (33.78cm)
Head Tube Angle (HA): 75.25°
Seat Tube Angle (SA): 71°
Bottom Bracket Height: 11.7" (29.72cm)
Standover Height (SO): 9.25" (23.49cm) - Seat Clamp: integrated
- Seat Post Diameter: 25.4mm
- Bottom Bracket: Mid BB
- Dropouts: heat treated, 6mm thick, 14mm slots
- Chain Tensioners: integrated
- Brake Type: U-Brake
- Brakemounts: with (screwable, M8)
- Brakemounts included with delivery: No
- Gyro compatible: Yes
- Features: wide rear end for fat 2.4" tires, Trevor Antillon Signature
- Model Year: 2021
