BOX Components "Box Three Pro" Front Wheel - 20 Inch (406)
- Weight : 0.85kg / 1.87lbs
- Packaging Unit: 1 Piece
- Product ID (PID): 45222
Weight
The heaviness of a BMX part, measured by weighing. It's worth noting that weight specifications for BMX parts can vary and may not always be precise. Several factors contribute to this:Manufacturer's weight specifications may be inaccurate or incomplete.The weight of two identical parts can also differ.We cannot weigh every individual part.For example, if there are handlebars in different heights, the manufacturer usually provides just one weight specification for all heights. When weighing two identical tires, you might get two different results.
Source: BMX Glossary
Found an error? Report it. 5 EUR voucher if confirmed.
Online: https://www.kunstform.org/en/box-components-box-three-pro-front-wheel-20-inch-406-p-45222
Printed: 10/30/2026
Printed: 10/30/2026
The BOX Components "Box Three Pro" Front Wheel - 20 Inch (406) is a ready to ride race front wheel, hand built in Southern California. The Box One rim in 20 x 1.75" (406) is a low profile double wall design without excess material. Single eyelets help prevent spoke pull-through and allow higher spoke tension.
The Box Three Pro front hub has a forged 6061 aluminum shell, two sealed 6902 bearings and a 10mm steel axle. It is laced 3-cross with 36 stainless steel 14 gauge spokes and brass nipples.
Facts: BOX Components "Box Three Pro" Front Wheel - 20 Inch (406)
- Wheel Size: 20" (406), 20 x 1.75"
- Rim: Box One
- Material: aluminum, double wall
- Holes: 36H - Hub: Box Three Pro
- Material: 6061 aluminum, forged
- Bearing: 2 x 6902, sealed bearings - Axle: 10mm, steel
- Spokes: stainless steel, 14 gauge, 3-cross, brass nipples
- Content: 1 front wheel
These details come from manufacturer and supplier data. Found an error? Report it, there is a 5 EUR voucher for every confirmed error.
