United Bikes "Prime Mover V3" BMX Frame
-
Weight : 2.26kg / 4.98lbs
Weight
The heaviness of a BMX part, measured by weighing. It's worth noting that weight specifications for BMX parts can vary and may not always be precise. Several factors contribute to this:Manufacturer's weight specifications may be inaccurate or incomplete.The weight of two identical parts can also differ.We cannot weigh every individual part.For example, if there are handlebars in different heights, the manufacturer usually provides just one weight specification for all heights. When weighing two identical tires, you might get two different results.Source: BMX Glossary
- Packaging Unit: 1 Piece
- Product ID (PID): 26921
The United Bikes "Prime Mover V3" BMX Frame is a collaboration with Bicycle Union, United Bikes and Tom Hooper. Tom Hopper designed the grafic which is printed by water transfer printing. The United Bikes "Prime Mover V3" BMX Frame is a solid, well built frame with no fancy gimmicks, using proper BMX frame geometry and a strong tube set throughout the frame can be used on park, trails & street and all frames include integrated chain tensioner.
Facts: United Bikes "Prime Mover V3" BMX Frame
- Wheel Size: 20"
- Material: 100% 4130 CrMo, down tube gussets, slim tapered tube set throughout, integrated headset
- Geometry:
Top Tube Length (TT): 21.25"
Chainstay Length (CS): 13.75" (34.92cm) - 14.1" (35.81cm)
Head Tube Angle (HA): 74.5°
Seat Tube Angle (SA): 71°
Bottom Bracket Height: 11.4" (28.96cm)
Standover Height (SO): 9" (22.86cm) - Seat Clamp: integrated investment cast
- Seat Post Diameter: 25.4mm
- Bottom Bracket: Mid BB
- Dropouts: Investment cast, 5mm thick, 14mm slots
- Chain Tensioners: integrated
- Brake Type: U-Brake
- Brakemounts: with (welded)
- Brakemounts included with delivery: Welded
- Gyro compatible: Yes
- Features: Tom Hooper signature frame, wide rear triangle for thick 2.4" tires
- Model Year: 2024
