e*thirteen "LG1 Race Carbon" MTB Crank Set
-
Weight : 0.44kg / 0.97lbs
Weight
The heaviness of a BMX part, measured by weighing. It's worth noting that weight specifications for BMX parts can vary and may not always be precise. Several factors contribute to this:Manufacturer's weight specifications may be inaccurate or incomplete.The weight of two identical parts can also differ.We cannot weigh every individual part.For example, if there are handlebars in different heights, the manufacturer usually provides just one weight specification for all heights. When weighing two identical tires, you might get two different results.Source: BMX Glossary
- Packaging Unit: 1 Set
- Product ID (PID): 36527
- Product safety
Found an error? Report it. 5 EUR voucher if confirmed.
The e*thirteen "LG1 Race Carbon" MTB Crank Set is the World Cup proven downhill carbon crank from e*thirteen in its fourth generation, with a narrower Q factor and a slimmer profile than its predecessors. The arms are compacted carbon with extra 3k weave on the front and rear faces against rock strikes, the 30mm spindle comes for 73mm and for 83mm bottom bracket shells and sits on the non-drive side. The chainline adjusts to non-Boost, Boost and Super Boost, the chainring sits on the Quick Connect interface: SL ring (8mm offset) for non-Boost and Boost, UL ring (5mm offset) for Super Boost. It is the one downhill crank made in 160mm for very low bottom brackets. Chainring and bottom bracket are not included.
Facts: e*thirteen "LG1 Race Carbon" MTB Crank Set
- Material Crank Arms: carbon, compacted fibre with 3k weave on front and rear faces, protective vinyl from the factory
- Material Crank Spindle: aluminium, 30mm
- Crank-Type: 2-piece
- Crank Arm Length: 160mm, 165mm, 170mm or 175mm
- Spindle Diameter: 30mm
- Spindle-Type: P3 Connect (polygon)
- Spindle: Spindle 73mm (68/73mm BB shell) or Spindle 83mm (83mm BB shell)
- Chainring Mount: Direct Mount (e*thirteen)
- Scope of Delivery: 1 crank set (crank arms, spindle, APS preload ring, installation tools, crank boots, sticker)
- Extras:
- for 73mm (73mm spindle) or 83mm (83mm spindle) bottom bracket shells
- spindle on the non-drive side, chainline adjustable to non-Boost, Boost and Super Boost
- chainring: SL (8mm offset) for non-Boost and Boost, UL (5mm offset) for Super Boost, not included
- 8mm self extractor, APS preload ring, crank boots
- bottom bracket not included
- weight 438g (165mm, 73 spindle), 444g (170mm, 73 spindle), 445g (175mm, 73 spindle), 451g (160mm, 83 spindle), 446g (165mm, 83 spindle), 452g (170mm, 83 spindle)
These details come from manufacturer and supplier data. Found an error? Report it, there is a 5 EUR voucher for every confirmed error.
